FLYMIND INDEPENDENT R&D

FLYM-PV10W000(2T3G)-A1

10W (10000mW) High-Power 2.4GHz Band Tactical VTX

High-efficiency 10W 2.4GHz video link transmitter built on Rogers 4350B RF substrate with CNC aluminum heat sink and active radiator fan.

Rogers 4350B PCB 10W Peak (10000mW) 2.4GHz (2T3G Band) CNC Active Cooling Fan 5s Slow Power-On

Input Voltage: 12-28V (2-6S Lipo)

RF Peak Power: 10W Peak (10000mW)

Frequency Band: 2.4GHz (2T3G Band)

Mounting Pattern: 30.5 x 30.5mm Standard

Antenna Interface: MMCX / SMA Connector

BEC Power Output: 5V OUT Regulated

DATASHEET SPECIFICATIONS

Technical Specifications Table

Model Name	FLYM-PV10W000(2T3G)-A1
Input Voltage	12-28V (2-6S Lipo)
Output Voltage (BEC)	5V DC Regulated Output for FPV / HD Cameras
RF Output Power	10W Peak (10000mW) Switchable
Operating Band	2.4GHz (2T3G Band)
Mounting Pattern	30.5mm x 30.5mm Standard Flight Controller Spacing
Thermal Management	High-Strength CNC Aviation Aluminum Shell + Active Radiator Fan
Startup Surge Protection	5-Second Delayed Slow Power-On Amplifier Protection
Control Protocol	SmartAudio (SA) & Pit Mode Support
Cable Wiring Connector	JST 6-Pin Connector (12-28V Input, GND, SA, 5V-OUT, GND, CVBS Video)
